ITCO Blend™ - Acid Corrosion Inhibitor is an organic free flowing liquid. It is essentially a high molecular weight amine derivative formulated to give optimum results. It contains Nitrogen but does not contain Lead, Arsenic or Chlorinated Hydrocarbons. This product is completely miscible with Hydrochloric Acid, Sulphuric Acid, etc. and it does not form sludge with the oils.
Acid Corrosion Inhibitor is used when acid attack such as Hydrochloric acid alone or mixed with Hydrofluoric acid is of extreme severity. This corrosion inhibitor is used when corrosive duty such as hydrochloric acid of 15% strength is used at temperature of 120°C at 1000 pounds of pressure per square inch. Such corrosive duties are encountered while acid fracturing of Limestone base is done. The corrosion rate expressed as loss in weight for N-80 steel, will not exceed 20 mg. Per square centimeter per 6 hours of exposure to above corrosive environment.
Acid Corrosion Inhibitor can also be used effectively in acid cleaning of Water Desalination Plants which have heat exchangers made of copper and cupro-nickel alloys.
The hydrochloric acid solution inhibited with Acid corrosion Inhibitor is best circulated through the equipment to be cleaned.
When circulation is not possible, the equipment should be filled with the inhibited acid and allowed to react for sufficient time to remove the objectionable deposits. To estimate the proper acid concentration, time etc. samples of the deposits to be removed can be tested in the laboratory prior to cleaning. If heating of the equipment or acid solution is desired to speed up the cleaning action, it should be done prior to the starting of the cleaning operation.
Manual on acid cleaning would be made on request.
The dosage of Acid Corrosion Inhibitor depends on the temperature and type of the acid used.
For 5% HCl up to a temperature of 85°C, 0.2% w/v is suggested i.e. 1000 litres of 5% HCl would require 2 Kg of the inhibitor.
When the temperature exceeds 85°C up to 115°C, a dosage of 0.3% w/v is suggested.
| Test | Unit | Specification |
|---|---|---|
| Appearance* | - | Orange to Brown cloured free flowing liquid |
| Specific Gravity@25°C | - | 0.98 ± 0.02 |
| pH (as such) | - | Acidic |
• 30Kg / 50Kg HDPE Carbuoys
• 100Kg and 200Kg HMHDPE barrels. Small packing can be offered on request
The containers should be opened with caution and this must be done under conditions of good ventilation.
Care should be taken to prevent any contact with skin and any other parts of the body. In case of contact with the skin wash the same with plenty of water followed by medical attention. The use of rubber gloves and goggles is recommended.
The test result of Acid Corrosion Inhibitor on mild steel coupon using Hydrochloric acid solution.The above inhibitor was tested for its efficiency.
Following were our findings.
| Test Against | 15% hydrochloric acid |
| Test Temperature | 120 ± 2 °C |
| Pressure | 1000 PSI |
| Duration of Test | 6 hrs. |
| Type of Steel | N – 80 |
| Dosage of Inhibitor | 3% |
| Wt. Loss due to Corrosion | Max. 15 mg / cm 2 |
| * The dose can be as 1% in case the test is performed at atmospheric pressure. | |
| Acid | Hydrochloric Acid 2% Ammonium Biflouride 0.5% |
| Acid Corrosion Inhibitor | Dosage 1.0% |
| Temperature | 900 °C ± 2 |
| Duration | 24 Hours |
| Metal | Metal loss Kg / m2 / 24 hrs | Coupon Condition |
|---|---|---|
| Copper | 0.0098 | No pitting |
| Brass | 0.0044 | No pitting |
| Acid | Hydrochloric Acid 15% |
| Acid Corrosion Inhibitor | 0.5% |
| Duration | 3 hours |
| Metal | Metal loss Mg / cm2 / 3 hrs | Coupon Condition | Temperature |
|---|---|---|---|
| Cu: Ni 90: 10 |
0.1087 | SI | 80° |
| Cu: Ni 90: 10 |
0.0553 | SI | 50° |
| Cu: Ni 70: 10 |
0.0954 | SI | 80° |
| SI- denotes highest shine on the coupon. | |||
| Acid | Hydrochloric Acid 15% |
| Acid Corrosion Inhibitor | |
| Dose of Inhibitor | 1% v/v (10 gallon per thousand gallon ) |
| Duration of Test | 6 Hours |
| Metal Coupon | N – 80 Steel |
| Test Condition | Results (Corrosion Rate Weight Loss) Mg / cm2 / 6 hrs or lb / ft2 / 6hrs |
|
|---|---|---|
| Temperature 102 ± 2°C or 215.6°F at 300ps. | 2.266 | 0.0046 |
| Temperature 102 ± 2°C or 248 - 250°F at atmospheric pressure | 2.44 | 0.0048 |
ITCO Blend™ - Biocide is a broad- spectrum especially designed for Oil F ield Sulphate Reducing Bacteria. Physically it is a pale yellow to dark brown clear free flowing liquid completely miscible with offshore and onshore water.
| Specifications |
|
||||||||||||
| Performance Data | Minimum Inhibitory Concentration (MIC) against various micro-organisms available in oilfield water is as follows:
|
||||||||||||
| Activity Range | Recommended dose for Oil field water is 100 -200 ppm. | ||||||||||||
| Packing | 50/100 / 200 litres HMHDPE containers. |
ITCO Blend™ - De-Emulsifier is a blend of phenol and fatty amine ethoxylates, specifically designed for separation of water from water in oil (W/O) emulsions. It is soluble in hydrocarbon solvents.
| Specifications |
|
||||||||||||
| Application | ITCO Blend™ - De-Emulsifier is used to lower down the water content in oil, particularly as a demulsifier for water in oil emulsions. De-Emulsifier has minimum efficiency of 50% at dose level of 40-70 ppm. | ||||||||||||
| Packing | • 50/100 Ltrs. HDPE /Carbuoys • 200 Ltrs. HMHDPE Barrels |
||||||||||||
| Handling | Avoid inhalation of vapours of the product. Avoid contact with skin & eyes. Wear suitable hand gloves & safety goggles while handling the product. Store in a cool place. |
ITCO Blend™ - De-Oiler is a product of aqueous blend of surfactants, suitable for use in oil- in water emulsions. It is soluble in water and insoluble in hydrocarbons.
| Specifications |
|
||||||||||||
| Application | ITCO Blend™ - De-Oiler is used to separate trace amount of oil from o/w emulsions. It is effective in the range of 5 to 15 ppm. It is efficiently used to reduce oil content from 50 to 80 % from the o/w emulsions. The actual injection rate which varies according to crude oil must be determined by the field test. | ||||||||||||
| Packing | • 50/100 Ltrs. HDPE /Carbuoys • 200 Ltrs. HMHDPE Barrels |
||||||||||||
| Handling | Avoid inhalation of the product. Avoid contact with skin and eyes. Use approved respirator, suitable gloves and safety goggles while handling the product. |
ITCO Blend™ - De-Scaler 12 M is a blend of phosphonates in the form of free -flowing liquid. It is specially designed to inhibit CaCO3 and CaSO4 scales at low dosage owing to its threshold effect. De-Scaler is readily soluble in fresh water & brines.
| Specifications |
|
||||||||||||||||||
| Performance Data |
ITCO Blend™ - De-Scaler Performance Test (NACE Standard TM0374-90)
|
||||||||||||||||||
| Packing | • 50/100 Ltrs. HDPE /Carbuoys • 200 Ltrs. HMHDPE Barrels |
||||||||||||||||||
| Handling | Avoid inhalation of any vapours. Avoid contact with skin & eyes. Use suitable gloves while handling the product. For more information, please refer SDS of the product. |
ITCO Blend™ - Emulsifier is an excellent surfactant to emulsify the acids (Typically 15 wt% Hydrochloric Acid) and light hydrocarbon phase (crude oil or diesel). Injection of the acid in this form (acid –in- diesel emulsion) will minimize acid-rock contact, which will result in the formation of deep worm holes. Emulsifying the acid will increase its viscosity and improve acid distribution in reservoirs. The foam will flow into the high permeability zones, causing the acid to flow into the light zones.
The acid-in-diesel emulsion consists of diesel (continuous phase) Hydrochloric acid (dispersed phase) and an emulsifier diesel act as a diffusion barrier between the acid and the rock, slowing the reaction rate of the acid with carbonate rock. This gives the acid the ability to penetrate deeper into the formation by creating wormholes and enhancing well productivity.
| Specifications |
|
|||||||||
| How To Use |
|
|||||||||
| Packing | It is available in bulk and 200 ltrs. drums. | |||||||||
| Storage and Handling | Store in closed containers. | |||||||||
ITCO Blend™ - Hydrill 100 is a high-performance shale inhibitor designed to provide an enhanced level of shale inhibition based for High Performance Water Based Muds in formations that contain swelling and reactive clays. Not only it gives excellent cuttings hardness, it is also compatible with all common Water Based Mud additives and does not have an adverse impact on properties.
ITCO Blend™ - Hydrill 100 does not require KCl or other salts to give excellent shale inhibition. It is Thermally stable & resistant to common contaminants. ITCO Blend™ - Hydrill 100 can be mixed directly into the fluid system either through the mud hopper, straight into the pit or gravity feed dispenser.
| Benefits | • Environmentally acceptable and non-toxic. • Does not have negative impact on mud properties. • Conventional glycols work best with K+ salts. • Reservoir compliant. • Optimum performance at 3–5 v/v in most shale types. |
| Packing | • 200 liter drums • 1000 liter IBCs. |
| Handling | Refer to ITCO Blend™ - Hydrill 100 SDS for health and safety guidance before handling and mixing. |
ITCO Blend™ - Hydrill 150 is an advanced, granular super-absorbent material that rapidly absorbs and retains large volumes of water from aqueous solutions, developing an effective lost circulation material.
It is a very effective drilling fluid solidifier (adsorbing the water phase of the drilling fluid). This has been specifically developed
| Benefits | • Excellent at sealing sand, gravel and fractured rock. • Capable of absorbing 200 times its own weight in water. |
| Packing | • 25 kg plastic pails • 27 pails per pallet. All pallets are stretch wrapped. |
| Handling | Refer to ITCO Blend™ - Hydrill 150 SDS for health and safety guidance before handling and mixing. |
ITCO Blend™ - Hydrill 200 is an environmentally friendly, non-damaging, next generation drilling fluid technology which can be used in a wide variety of drilling and completion applications.
When used in fresh water or a variety of brines, ITCO Blend™ - Hydrill 200 forms the basis of a high-performance water-based drilling fluid. The ITCO Blend™ - Hydrill 200 Nano-chemistry provides a highly shear thinning fluid, with both fluid loss control and shale encapsulation via its unique membrane forming characteristics.
ITCO Blend™ - Hydrill 200 enhances drilling performance – significantly improving hole cleaning & borehole stability.
| Benefits | • Environmentally acceptable – Nontoxic and biodegradable • Extremely effective hole cleaning • Greatly enhanced rates of penetration |
| Packing | • 5kg bags • 25kg plastic bags |
| Handling | Refer to ITCO Blend™ - Hydrill 200 SDS for health and safety guidance before handling and mixing. |
ITCO Blend™ - Hydrill 250 is an ultra-low invasion additive that protects the formation by minimizing fluid and pressure invasion into pores and micro-fractures. By forming a low permeability seal, it limits the transmission of wellbore pressure to the matrix, minimizing formation breakdown and preventing fracture propagation, and restricts fluid invasion into micro fractures that can destabilize tectonically weak shales.
It is essentially inert in terms of standard drilling fluid properties and can be used in water based & oil-based fluids with a mud weight ranging from 9ppg to 18ppg with negligible changes to viscosity or other properties of the drilling fluid.
| Benefits | • Protects mechanically weak and interbedded shales, to prevent sloughing, washouts, hole closure and collapse. • Eliminate differential sticking in high permeability formations. • Minimizes downhole losses by preventing induced losses. • Enhances production capability by minimizing invasion into depleted reservoirs. • Stable to temperatures in excess of 200°C (400°F). |
| Packing | • 25lbs bags • 48 bags per pallet |
| Handling | Refer to ITCO Blend™ - Hydrill 25 0 SDS for health and safety guidance before handling and mixing. |
ITCO Blend™ - Poly Anionic Cellulose (PAC) features high purity, high replacement and well distribution and can be taken as thickener, rheology modifier and fluid loss agent. PAC HV and PAC LV with excellent filtration reduction are indispensable products of slurry combination. The High quality PAC is white flowing powder and its water solution is transparent viscous liquid.
| Functions & Properties | • Rapidly dissolved in cold water or hot water • Able to be thickener, rheology control agent, adhesive, stabilizer, protective glue, suspending agent and water retaining agent. • In oil drilling industry, PAC is a kind of good drill slurry treating agent and fluid dosing material, featuring high mud yield and excellent salt resistance. • To fresh-water mud, seawater mud and saturated brine mud, PAC is an excellent filtration reducer and has superior viscosity increasing ability and high temperature resistance (150°C ), applicable for formulating fresh water, seawater and saturated brine completion fluid. • Besides, it can formulate completion fluids with various densities when weighing calcium chloride and can make the completion fluid have certain viscosity and lower filtration loss. • PAC products meet the standards of OCMA and API 13A. |
||||||||||||||||||||||||||||||||
| Performance Data |
|
||||||||||||||||||||||||||||||||
ITCO Blend™ - Poly Anionic Cellulose (Low & High Viscosity)
| Synonyms | • Sodium Carboxymethyl Cellulose • Carboxymethylcellulose Sodium Salt |
||||||||||||||||||||||||||||||||
| Molecular Formula | C28H30Na8O27 | ||||||||||||||||||||||||||||||||
| Molecular Structure |  |
||||||||||||||||||||||||||||||||
| Performance Data |
|
||||||||||||||||||||||||||||||||
ITCO Blend™ - Scavenger is a Hexahydro-1,3,5-tris (2-hydroxyethyl)-s-triazine based H2S scavenger for oil filed applications. It is slightly yellowish to amber color clear liquid. It is highly active bactericide and fungicide. It is soluble in water, alcohols and propylene glycols. It is an economic and highly effective scavenger for H2S.
| Specifications |
|
|||||||||||||||||||||
| Application | It can be used as an H2S scavenger and is compatible with other anionic, cationic, and nonionic’s at the proper pH range of 9-11. Product will lose activity at a < pH 5.0 as well as in the presence of Hydrogen peroxide at a pH >10. | |||||||||||||||||||||
| Handling & Storage | Store in dry cool place. Keep in closed containers below 55°C. Avoid contact with the eyes, nose, and prolonged skin contact. Wash thoroughly after handling products. |
ITCO Blend™ - Scavenger with Anti Scalant is a cyclic tertiary triamine. It is mainly used as a scavenger for sour gases like H2S & mercaptans in liquid or gaseous hydrocarbons streams. It reacts with H2S or mercaptan resulting in the formation of dithiazines, a family of products known to corrosion inhibitors. It is an economic and highly effective scavenger for H2S.
| Synonyms | • 1,3,5-trimethyl hexahydro-s-triazine • 1,3,5-trimethyl hexahydro-1,3,5-triazine • 1,3,5-trimethyl trimethylenetriamine |
|||||||||||||||||||||
| Molecular Formula | C6H15N3 | |||||||||||||||||||||
| Molecular Weight | 129.2 g/mol | |||||||||||||||||||||
| Specifications |
|
|||||||||||||||||||||
| Application | ITCO Blend™ - Scavenger with Anti Scalant is mainly used as a scavenger for sour gases like H2S & Mercaptans in liquid or gaseous hydrocarbons streams, in areas where floor spacing is rare like off-shore platforms, ships etc. It can be used in conjunction with other hexahydro-triazines derived from other primary amines. e.g. diethanolamine(DEA) or methoxypropylamine (MOPA) |
ITCO Blend™ - Water Corrosion Inhibitor CBO is an Organic base free flowing liquid Oil line Corrosion Inhibitor. It is essentially a high molecular weight derivative formulated to give optimum results. It contains Nitrogen but does not contain Lead, Arsenic, chlorinated hydrocarbons. This product is completely dispersible in water and soluble in oil and hydrocarbon.
Water Corrosion Inhibitor is specially designed for the protection of oil transportation pipelines. Inhibitor efficiency is 80% minimum in carbondioxide saturated 3.2 % NaCl brine at 50°C temperature.
| Usage | Water Corrosion Inhibitor CBO is best applied continuously in the following way. • 35 – 70 Kg/Millions of Cubic Meter of oil for continuous application. |
||||||||||||||||
| Specifications |
|
||||||||||||||||
| Packing | 30Kg / 50Kg HDPE Carbuoys/ 100Kg and 200Kg HMHDPE barrels. | ||||||||||||||||
| Handling | The containers should be opened with caution and this must be done under conditions of good ventilation. Care should be taken to prevent any contact with skin and any other parts of the body. In case of contact with the skin wash the same with plenty of water followed by medical attention. The use of rubber gloves and goggles is recommended. | ||||||||||||||||
| Performance Test |
Corrosion Media • The corrosion Media consists of 3.2% NaCl (LR) solution in distilled water having dissolves CO2 contents in range of 1250 ± 50ppm at 24 ± 2°C
Metal Coupons • The coupons should be of AP15LGr.B. Test Temperature 50 ± 2°C Corrosion Inhibitor Dose 35 ppm (w/v) Exposure Period 168 Hours for Static Condition, 24 Hours for Dynamic Condition |
||||||||||||||||
|
|||||||||||||||||
ITCO Blend™ - Water Corrosion Inhibitor CBW is an organic base free flowing liquid formulation suitable for inhibition of corrosion. It is essentially a blend of high molecular weight fatty acid / fatty amine derivatives and does not contain chlorinated hydrocarbons.
It is soluble in fresh water and brines and is dispersible in hydrocarbons.
Water Corrosion Inhibitor is versatile product and can provide protection efficiency of 90% minimum on API 5LX Gd B material at 50°C under various conditions.
| Specifications |
|
||||||||||||||||||
| Application | Water Corrosion Inhibitor CBW can be used continuously at dosage of 5 to 50 ppm depending upon the severity of corrosive conditions. | ||||||||||||||||||
| Packing | • 30Kg / 50Kg HDPE Carbuoys • 100Kg and 200Kg HMHDPE barrels |
||||||||||||||||||
| Handling | The containers should be opened with caution and this must be done under conditions of good ventilation. Care should be taken to prevent any contact with skin and any other parts of the body. In case of contact with the skin wash the same with plenty of water followed by medical attention. Use of rubber gloves and goggles is recommended while handling the product. |
Integrated Chemical Specialties, a division of ITS USA strives to provide our clients with the highest quality, competitively priced product with exceptional customer service and experienced logistical support.
Disclaimer: The information above is believed to be accurate and represents the best information currently available to us. There are no warranties which extended beyond the information in the TDS. Integrated Chemical Specialties, a division of Integrated Traffic Systems USA warrants this product to conform to its own specifications. Integrated Chemical Specialties, a division of Integrated Traffic Systems USA liability on this warranty is limited to the return of the purchase price of this product. The buyer assumes all risks and liability resulting from the use of this product. Integrated Chemical Specialties, a division of Integrated Traffic Systems USA neither assumes nor authorizes any person to assume for it any other liability in connection with the sale or use of this product. We make no warranty of merchantability or any other warranty, express or implied, with respect to such information, and we assume no liability resulting from its use. Users should make their own investigations to determine the suitability of the information for their particular purposes. In no way shall Integrated Chemical Specialties, a division of Integrated Traffic Systems USA will be liable for any claims, losses, or damages of any third party or for lost profits or any special, indirect, incidental, consequential or exemplary damages, howsoever arising, even if Integrated Chemical Specialties, a division of Integrated Traffic Systems USA has been advised of the possibility of such damages. Request a SDS if needed. Note: Products protected by valid patents are not offered for sale in countries, where the sale of such products constitutes a patent infringement. The Liability for patent infringement is exclusively to be understood as buyer’s risk. Products currently covered by valid US Patents are offered for R&D use in accordance with 35 USC 271(e)+A13(1)
